New! Infrared motion sensor BRAVO Vivalux

New! Infrared motion sensor BRAVO Vivalux

We present you the most compact and thin infrared motion sensor BRAVO SR 36 with a detection range 360°.

BRAVO SR 36 combines exceptional functionality in mind its size and elegant appearance. This makes it applicable in all cases where the architectural appearance of the premises is essential.

The sensor turns on or off lights automatically, taking into account the infrared radiation from the human body as a control signal which triggers the lighting. BRAVO SR 36 automatically detects day and night.

The product is suitable for indoor use (staircases, corridors, external parts of buildings – garages, etc.).

TECHNICAL SPECIFICATION

  • Working temperature: -20 to 40° C
  • Ingress protection: IP20
  • Power supply: 220-240V/AC
  • Power frequency: 50/60Hz
  • Working humidity: <93% RH
  • Ambient lighting: <3-2000 Lux (adjustable)
  • Rated load: 2000W for incandescent lamps and 1000W of energy-saving lamps
  • Time delay: - min.10 sec ± 3 sec./Max. 15 min. ± 2 min
  • Detection range: 360°
  • Detection distance: max. 6 meters (<24° C)
  • Installation height: 2.2 to 4 m
  • For ceiling mounting
  • Detection moving speed: 0.6-1.5 m/sec.

The sensor detects the temperature changes. Avoid its mounting near heat sources, reflective surfaces, air-conditioning systems, as well as to easily movable objects which move as a result of air flow.
